- Survey-I SURVEYING –I List of Practical (Minimum 15 practical should be performed out of the following) 1) Measurement of distance by ranging and chaining. 2) Locating various objects by chain & cross staff surveying. 3) Determination of area of polygon by chain and cross staff survey.
- Definition of Surveying 1.1.1 B. Importance of Surveying 1.1.1 C. Purpose of Manual 1.1.2 D. Scope of Manual 1.1.2 1-02 Organization A. Division of Plats and Surveys 1.2.1 B. Duties and Responsibilities 1.2.5 1-03 Public and Internal Relations A. General 1.3.1 B. Relations With the Public 1.3.1 C. Relations with Property Owners 1.3.2.
Theodolite ET-Series
Centering the Theodolite over the instrument station Approximate leveling of Theodolite with the help of the tripod legs only Centering It is the operation by which the vertical axis of the theodolite represented by a plumb line is made to pass through the mark of instrument station on the ground. Approximate leveling. The theodolite has two power options: Disposable and rechargeable batteries. The rechargeable batteries are supplied in a sealed pack. The disposable batteries are inside a similar shaped pack with a sliding door. To remove the pack, turn the knob until the mark “ ” points to UNLOCK, then remove the battery pack. Theodolite traversing lab manual. Distance measuring instrument, pdf theodolite traversing. Surveying multiple choice questions, mathematics common dumpy level, ii lab manual pdf. Surveying notes pdf. Rehabilitation wastewater collection systems. Civil engineering computer science. Optical theodolite traversing.
Absolute Encoding
Dual Sides
Large Display
Theodolite Surveying Equipment
Specifications
Theodolite Surveying Pdf
ET-05/ET-05L | ||||||||
Angle Measurement | ||||||||
Measuring method | Absolute code | |||||||
Raster diameter | 79mm | |||||||
Min display unit | 1″/ 5″Selectable | 10' | ||||||
Accuracy | 2″ | 5″ | ||||||
Horizontal angle | Dual | Dual | ||||||
| Vertical angle | Dual | Dual | ||||||
Telescope | ||||||||
Image | Erect | |||||||
Tube length | 157mm | |||||||
Effective aperture | 45mm (EDM:50mm) | |||||||
Magnification | 30× | |||||||
Field of view | 1°30′ | |||||||
Minimum Focusing Distance | 1.4m | |||||||
Resolving Power | 3″ | |||||||
| Stadia ratio | ||||||||
| Stadia constant | 0 | |||||||
Auto Compensator | ||||||||
System | Liquid-electric detection | Plate Vial | ||||||
Work range | ±3′ | |||||||
Resolving power | 1″ | |||||||
Vial | ||||||||
Plate vial | 30″／2mm | |||||||
Circular vial | 10′／2mm | |||||||
Optical Plummet | ||||||||
Image | Erect | |||||||
Magnification | 3× | |||||||
Focusing range | 0.5m～∞ | |||||||
Field of view | 5° | |||||||
Display | ||||||||
Type | LCD display 2sides | |||||||
| Laser Pointer | ||||||||
| Laser Range | be seen up to 100 meters away | |||||||
On-board Battery | ||||||||
Power supply | Rechargeable Ni-H battery/AA Battery | |||||||
Voltage | DC 6V | |||||||
Continuous operation time | 10hours | |||||||
Size & weight | ||||||||
Dimension | L145*H318*W179 | |||||||
Weight | 5.2㎏ | |||||||
